SDVH12B

φ12mm OD, SUS304 shell case, spring loaded type Output: Analog output 4-20mA,0-5V,0-10V Digital output: RS485 Stroke length is max 500mm

Description
Data download

The inductance measuring probe is also known as LVDT sensor, which is the upgrade model of standard spring loaded displacement sensor, belongs to the differential transformer displacement sensor (LVDT). Models characterized by the φ12mm OD, built-in spring, probe self-reset, high mechanical repeatability, effective stroke 0-5mm, 9-28Vdc power supply, output two-wire system 4-20mA, three-wire system 0-5V, three-wire system 0-10V, 4-wire RS485-Modbus signal. Accept non-standard customization.


Applications


Hydraulic cylinder position sensing
Roller gaps alignment
Valve position sensing
TIR measurements
Brake system inspections
